CP654ULHTSP
CP654ULHTSP – Large Plenum Rated Condensate Pump, 460V, 65 Ft Max Lift, Rated to 212 °F
Beckett’s heavy-duty CP654ULHTSP large plenum rated condensate pump designed to be installed in plenum locations and handles condensate up to 212° F. This robust pump includes a reliable two float design as well as one of our largest motors to ensure efficient and quiet operation, plus longterm durability. The ideal solution for high lift installations up to 65’ lift with AC units, humidifiers, dehumidifiers, high-efficiency furnaces, boilers, and other equipment. The pump has a built-in safety switch, a one-gallon tank, a replaceable check valve, and a pre-wired terminal block. This unit is also capable of handling high-acidity condensation. All CB65 condensate pumps are UL/CUL listed.
CP654ULHTSP – Large Plenum Rated Condensate Pump, 460V, 65 Ft Max Lift, Rated to 212 °F
Product Description
- 460V, 50/60Hz, 390 Watts
- Shutoff/Max lift: 65 ft
- Flow 476 GPH @ 1 ft
- UL tested to UL2043 for Plenum Applications
- High-temperature unit rated for applications up to 212° F
- 1/2" Copper Discharge
- 1" inlet
- Tank capacity 1.0 US Gallon
CP654ULHTSP – Large Plenum Rated Condensate Pump, 460V, 65 Ft Max Lift, Rated to 212 °F
Product Specifications
| Application | Condensate |
|---|---|
| Sub Application | Pump - Condensate, Pump - High Temperature, Pump - Plenum Rated |
| Pump Size | Large |
| Shutoff/Max Lift (ft) | 65 Ft |
| Voltage | 460 |
| Flow GPH @ 1 ft | 476 |
| Tank Size | 1 Gal. |
| Plenum Rated | Yes |
| Max Water Rating (°F) | 212 F |
| Safety Switch | Yes |
| Discharge Size | 1/2" Compression |
| Item Height (In) | 10.5 In |
| Item Length (In) | 12 In |
| Item Width (In) | 6 In |
